Soundproof Single Leaf Fireproof Entry Doors With Inlayed Fire Expansion Strips
Soundproof Single Leaf Fireproof Entry Doors With Inlayed Fire Expansion Strips
| Minimum Order Quantity : | 1 set | Price : | negotiable |
|---|---|---|---|
| Packaging Details : | Inside Bubble Bags+ Strong Carton+Wooden Frame | Delivery Time : | 35 Days After Payment Received |
| Payment Terms : | western union, moneygram,cash, l/c, t/t | Supply Ability : | 600 Sets per Day |
| Place of Origin: | CHINA | Brand Name: | ZHONGWO |
|---|---|---|---|
| Certification: | UL, CCC | Model Number: | ZW-GMFD09 |
|
Detail Information |
|||
| Door Leaf: | 1 | Door Mirror: | 1 |
|---|---|---|---|
| Fire Lock: | 1 | Fire Hinge: | 4 |
| Highlight: |
fire rated entry door, flat entrance fire doors |
||
Product Description
Single-Leaf Fireproof Entry Doors Fire Rated Apartment Entry Doors
Technical Specification
1. Overlap Value of Door Leaf and Door Frame meet the standards requirements.
2. The Length Difference of the Two Diagonal of Door Frame Notch meet the standards requirements.
3. The Length Difference of the Two Diagonal of Door Leaf meet the standards requirements.
4. The Distortion of the Door Leaf meet the standards requirements.
Product Description
The door frame is also equipped with inlayed Fire expansion strips and installed with Fire seals.By closing there is no impact sound to hear.And thirdly the crossbeam and mullion are welded in 45 degree. The door fan made of high quality cold rolled galvanized steel plate is bent accurately through bending machine, inside of which it is filled with green environment friendly perlite plates which are key to its Fire funktion,and charackters of heat insulation and sound insulation. As to the surface treatment man introduces the process technology without welding spots, thus flat appearance.
The Fire and anti-theft door of Zhongwo Company has excellent anti-theft performance and super Fire performance. Because of its solid structure and simple shape, it is widely used in high-rise residential buildings. The door frame which is made of high quality galvanized steel strip is rolled forming at one tiem thtough the special production line.
Technical Parameters
| Door Closer | 1 |
| Door Frame | 1.2mm Cold Rolled Galvanized Steel Sheet |
| Door Frame Type | Binding |
| Sideboard Width | 100mm 120mm(with earing) |
| Door Leaf | 1 65mm |
| Door Mirror | 1 |
| Fire Lock | 1 |
| Fire Hinge | 4 |
| Fire Intumescent Seals | 12*2+15*6 (W*T mm) |
| Perlite Fire Door Core Board | 1 300kg/m³±10% |
| Door Leaf Panel | 2 0.8mm Cold Rolled Galvanized Steel Sheet |
| Pattern of Panel | 6 Square Block |
| Class | A |
| Grade | B |
| Fire Resistance Rating | 1.0 Hour |
| Name | Fire-Proof Anti-Thief Door |
| Dimension | 1000*2100 (mm) |
| Standards | GB12955-2008 |
