Gal. Steel Fire Rated Exterior Pair Door For Apartment/ Steel Insulated Fire Door/ 1 Hour Fire Rating
Gal. Steel Fire Rated Exterior Pair Door For Apartment/ Steel Insulated Fire Door/ 1 Hour Fire Rating
| Minimum Order Quantity : | 1 set | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | PEP Paper on both sides+ Foam Channel Around 4 Edges and Corners + Foam Plate on both sides on PEP Paper + Strong Carton | Delivery Time : | 30 days after reception of down payment |
| Payment Terms : | western union, moneygram,cash, l/c, t/t | Supply Ability : | 600 sets per day |
| Place of Origin: | CHINA | Brand Name: | ZHONGWO |
|---|---|---|---|
| Certification: | BS， WHI， UL, CCC | Model Number: | ZW-GM09 |
|
Detail Information |
|||
| Standard: | BS476:22/ EN1634:1 | Fire Rating: | 30/60/90/120 Mins |
|---|---|---|---|
| Finish: | Powder Coating; Wood Grain | Thickness Of Door Leaf: | 40/45/55 Mm |
| Thickness Of Steel Sheet For Door Leaf: | 0.8/1.0 /1.5 Mm | Thickness Of Steel Sheet For Door Frame: | 1.2/1.5/2.0 Mm |
| Frame Depth: | 90/112/120 Mm | Color: | Customized |
| Size: | Customized Size | Accessory: | International & Chinese Brand |
| Highlight: |
steel fire door, fire rated interior doors |
||
Product Description
1.2 mm Galvanized Steel 30/ 60/ 90 min Office Buildings Insulated Fire Doors Doha
Steel Insulated Fire Door
Product Description
Material: The door frame adopts cold rolled galvanized steel plate with thickness of no less than 1.2mm.
The door leaf adopts cold rolled galvanized steel plate with thickness of no less than 0.8mm.
Hardware fitting backboard adopts ordinary steel plate with thickness of no less than 3.0mm.
Hardware fittings:The famous high-grade fire lock, door closer, fire prevention hinge, sequencer, latch etc.with characteristics that flexible, safe, reliable, and so on. They are approved by the national recognized inspection authority, and the performance meet GB12955-2008 appendix A, B, C, D.
The Maximum Opening size is 2100(W)*2300(H) (mm)
Fire Resistance Rating(FRR):
Grade A: 1.5 Hours
Grade B: 1.0 Hour
Grade C: 0.5 Hour
Fire Resistance Rating Classification
| Name | Fire Resistance Performance | Code | |
|
Fully Heat Insulated Doorsets(Class A)
|
Fire Insulation ≥0.50h
Fire Integrity ≥0.50h |
A0.50
(Grade C) |
|
| Fire Insulation ≥1.00h
Fire Integrity ≥1.00h |
A1.00
(Grade B) |
||
| Fire Insulation ≥1.50h
Fire Integrity ≥1.50h |
A1.50
(Grade A) |
||
| Fire Insulation ≥2.00h
Fire Integrity ≥2.00h |
A2.00 | ||
| Fire Insulation ≥3.00h
Fire Integrity ≥3.00h |
A3.00 | ||
| Partially Heat Insulated Doorsets(Class B)
|
Fire Insulation ≥0.50h |
Fire Integrity ≥1.00h | B1.00 |
| Fire Integrity ≥1.50h | B1.50 | ||
| Fire Integrity ≥2.00h | B2.00 | ||
| Fire Integrity ≥3.00h | B3.00 | ||
| No Heat Insulated Doorsets(Class C)
|
Fire Integrity ≥1.00h | C1.00 | |
| Fire Integrity ≥1.50h | C1.50 | ||
| Fire Integrity ≥2.00h | C2.00 | ||
| Fire Integrity ≥3.00h | C3.00 | ||
Technical Parameters
| Items | Grade A Steel
Insulated Fire Door |
| Fire Protection Time (H) | 1.5 |
| Code | A1.50 |
| Thickness of Door Leaf
(mm) |
55 |
| Thickness of Door Frame
(mm) |
120 |
| Thickness of Steel plate for Door Leaf (mm) | 0.8 |
| Thickness of Steel plate for Door Frame (mm) | 1.2 |
| Fire Prevention Board | Available |
| Filled Material | Perlite Fireproof Board |
| Door Leaf | 2 |
| Fire Closer | 2 |
| Fire Sequence | 1 |
Application
Large-scale shopping malls, high-grade office buildings, top-three hospitals, office buildings, schools, hotels, libraries, museums, business centers and other high-rise buildings and fire exit in public places.
