Steel FD30 Fire Door With Fireproof Glass Color Can Be Customized
Minimum Order Quantity :
1 set
Price :
Negotiable
Packaging Details :
PE Paper+Double Layer Strong Carton or wooden palletPE Paper+Double Layer Strong Carto…
Delivery Time :
45 Days After Payment Received
Payment Terms :
western union, moneygram,cash, l/c, t/t
Supply Ability :
600 Sets per Day
Place of Origin:
CHINA
Brand Name:
ZHONGWO
Certification:
BS， WHI， UL, CCC
Model Number:
ZW-CBM04
DETAIL INFORMATION
PRODUCT DESCRIPTION
Detail Information
Material:
Galvanized Steel
Fire Rating:
30/60/90/120/150 Min
Thickness Of Door Leaf:
45/50/55/60/72 Mm
Thickness Of Door Frame:
120/130/160 Mm
Face Sheet Of Sash:
1.0/1.2/1.6 Mm
Face Sheet Of Frame:
1.5/1.6/2.0 Mm
Infilling:
Fireproof Perlite Board
Finish:
Powder Coated, Primer Paint
Highlight:
fire door keep closed
,
self closing fire rated door
Product Description
Steel FD30 fire door with fireproof glass color can be customized
Self Closing Fire Door
Zhongwo single open powder coating steel insulated fire door with vertical vision panel consists of various fire doors of different colors, sizes, fire ratings and surface treatment. And the sizes and fire ratings of vertical vision panel match individually the sizes and fire ratings of the entire doors. Fire rating of doors can be divided into three kinds: 30mins, 60mins and 90mins, so as the vertical vision panels. We not only provide you with fire doors with vertical vision panels of standard sizes (1000X 2300, 700X 2300, 700X 2100, 700X 2000) and popular colors on our color swatch (cold gray white, dark gray, milky white, matte orange and beige etc.), we can also customize fire doors for you 100% as your request.
Specification
Product Name
Zhongwo Fire Rated Steel Doors
Fire Rating
20/30/60/90/150/180mins
Standard
NFPA,ANSI/UL 10B,UL10C
BS476-22, EN1634-1:2008
Material of Door Leaf
Galvanized Steel Sheet
Material of Door Frame
Galvanized Steel Sheet
Thickness of Steel Sheet of Door Leaf
20-18-16 Ga. (1.0/1.2/1.6 mm)
Thickness of Steel Sheet of Door Frame
18-16-14 Ga. (1.2/1.6/2.0mm)
Thickness of Door Leaf
US Standard Door: 40/45 mm
BS Standard Door: 45/50/55/64 mm
Frame Depth
120/130/160 mm
Weight
25-35Kg/㎡
Size
Single Door: 3’X7’; 4’X8’
Double Door: 6’X7’; 8’X8’
Or customized
Open Style
Swing Open
Infilling Material
Standard: Fireproof Perlite Board
Options: Honeycomb Paper, Mineral Wool, Polyethylene Foam
Surface Treatment
Prime Paint(UV/PU), Powder Coating, Wood Grain
Color
Milk White, Matte Orange, Dark Gray, Cold Gray White or as Request
Glass
Standard: American or British Standard Tested Clear or Wired Glass
Or Customized As Request
Fireproof Seal Strip
FPJ-B-20X 2
FPJ-A-15X 2
Or Customized
Warranty
2 years
Package
PE Paper+Double Layer Strong Carton or wooden pallet
Delivery Time
45Days After Payment Received
Hardware
As standard we equip every door with galvanized steel hinges, locksets and high quality door closers. We can also send you panic push bar, fire bolts, magnetic door stoppers or other accessories as your request. Melting temperature of hardware installed in doors should be no less than 950℃.
Besides, we also have stainless steel hardware when you want.
Reinforcements
· Top and bottom of doors shall be reinforced with continuous 16-gauge steel channels, spot welded to both sides of doors.
· Hinge reinforcements shall be 11-gauge steel angle, 12″ long
· Cylindrical lock reinforcement shall be 16-gauge with 11-gauge thread depth. Other lock and closer reinforcements shall be 12-gauge.
· Doors shall be reinforced for all surface type hardware. Drilling and tapping of surface hardware to be done in the field by the erector.
· Edges of door shall be continuously seam welded, ground, and filled to ensure a smooth finish.
Glass
A. Reinforcement channel is provided.
B. Glass frame and glazing bead is steel.
C. Glass is UL listed glazing material.
D. Maximum allowable glass area:2 Hours, 100 sq. in. Per door leaf (Fire lite)
Package
Package method is vital to ensure the safety and to avoid any damage in transportation, so we values very much the correct package.
Standard: PE Paper+Double Layer Strong Carton or wooden pallet
We can also pack doors and frames as your request, just exchange the details with us.
